Descripción

Tarjeta Madre micro ATX AMD A520 (Ryzen AM4) con soporte M.2, Ethernet de 1 Gb, HDMI / D-Sub, SATA 6 Gbps, USB 3.2 Gen 1 Tipo A

Socket AMD AM4: Listo para procesadores de escritorio Ryzen™ 5000 Series / 4000 G-Series / 3000 Series.
Enfriamiento completo: Disipador de Chipset y Fan Xpert.
Conectividad ultrarrápida: Compatibilidad con M.2, Ethernet de 1 Gb, USB 3.2 Gen 2 tipo A.
5X Protection III: Múltiples protecciones de hardware para la protección integral del sistema.

Especificaciones

Componente	Especificaciones
CPU	AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors
Chipset	AMD A520
Memoria	2 x DIMM, Max. 64GB, DDR4 4866(O.C)/4600(O.C)/... MHz Un-buffered Memory
	Dual Channel Memory Architecture
	ECC Memory (ECC mode) support varies by CPU.
Gráficos	1 x D-Sub
	1 x HDMI 2.1(4K@60HZ)
Slots de Expansión	AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors:
	1 x PCIe 3.0 x16 (x16 mode)
	AMD A520 Chipset:
	2 x PCIe 3.0 x1
Almacenamiento	Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports
	AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series Desktop Processors:
	1 x M.2 Socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
	AMD A520 Chipset:
	4 x SATA 6Gb/s port(s),
	Support Raid 0, 1, 10
LAN	Realtek RTL8111H 1Gb Ethernet
	ASUS LANGuard
Audio	Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC
	- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
	Audio Feature :
	- Audio Shielding
	- Dedicated audio PCB layers
	* Choose the chassis with HD audio module in front panel to support 8-channel audio output.
Puertos USB	Rear USB Port (Total 6)
	4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
	2 x USB 2.0 port(s)(2 x Type-A)
	Front USB Port (Total 6)
	2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
	4 x USB 2.0 port(s)(4 x Type-A)
Software Features	ASUS Exclusive Software
	Armoury Crate
	AI Suite 3
	- Performance and Power Saving Utility
	TurboV EVO
	EPU
	Digi+ VRM
	Fan Xpert
	- EZ update
	ASUS CPU-Z
	AI Charger
	DAEMON Tools
	Norton Anti-virus software (Free Trial for 60 days)
	WinRAR
	UEFI BIOS
	ASUS EZ DIY
	- ASUS CrashFree BIOS 3
	- ASUS EZ Flash 3
	- ASUS UEFI BIOS EZ Mode
ASUS Special Features	ASUS 5X PROTECTION III
	- ASUS DIGI+ VRM
	- ASUS LANGuard
	- ASUS Overvoltage Protection
	- ASUS SafeSlot Core
	- ASUS Stainless-Steel Back I/O
ASUS Q-Design	- ASUS Q-DIMM
	- ASUS Q-Slot
ASUS Thermal Solution	- Aluminum heatsink design
Puertos I/O Traseros	1 x PS/2 keyboard/mouse combo port(s)
	1 x D-Sub
	1 x HDMI
	1 x LAN (RJ45) port(s)
	4 x USB 3.2 Gen 1 (blue) Type-A
	2 x USB 2.0
	3 x Audio jack(s)
Internal I/O	1 x CPU Fan connector(s)
	1 x Chassis Fan connector(s)
	1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
	2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
	1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3
